CAT24C04C5ATR
IC EEPROM 4KBIT I2C 5WLCSPManufacturer: onsemi
Categories: Memory
Quality Control: Learn More
The onsemi CAT24C04C5ATR is a 4Kbit serial EEPROM memory device featuring an I2C interface. This non-volatile memory component operates with a clock frequency of up to 400 kHz and offers an access time of 900 ns. The memory organization is 512 x 8 bits. Designed for surface mount applications, it is supplied in a compact 5-WLCSP (0.86x0.84) package, presented on a Tape & Reel (TR). The CAT24C04C5ATR supports a wide supply voltage range of 1.7V to 5.5V and has a word/page write cycle time of 5ms. This component is suitable for various applications including consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 5-XFBGA, WLCSP |
| Mounting Type | Surface Mount |
| Memory Size | 4Kbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 1.7V ~ 5.5V |
| Technology | EEPROM |
| Clock Frequency | 400 kHz |
| Memory Format | EEPROM |
| Supplier Device Package | 5-WLCSP (0.86x0.84) |
| Write Cycle Time - Word, Page | 5ms |
| Memory Interface | I2C |
| Access Time | 900 ns |
| Memory Organization | 512 x 8 |
| Programmable | Not Verified |
