NCV97310MW50R2G
IC REG QUAD BUCK/LNR SYNC 32QFNManufacturer: onsemi
Categories: Linear + Switching
Quality Control: Learn More
The onsemi NCV97310MW50R2G is a versatile power management IC featuring four independent voltage regulators. This device integrates two synchronous buck converters and two linear (LDO) regulators within a compact 32-QFN (5x5) package. The buck converters operate with a switching frequency range of 2MHz to 2.6MHz, offering high efficiency for step-down conversion. The LDOs provide stable voltage outputs with low noise. This component is designed for automotive applications, as evidenced by its AEC-Q100 qualification and an operating temperature range of -40°C to 105°C. Output 1 is fixed at 5V with a 3A capability, while outputs 2 and 3 are adjustable from 1.2V to 3.3V, each supporting up to 1.5A. The input voltage range is from 4.1V to 18V. Mounting is via surface mount technology.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 4.1V ~ 18V |
| Frequency - Switching | 2MHz ~ 2.6MHz |
| Topology | Step-Down (Buck) Synchronous (2), Linear (LDO) (2) |
| Supplier Device Package | 32-QFN (5x5) |
| Voltage/Current - Output 1 | 5V, 3A |
| Voltage/Current - Output 2 | 1.2V ~ 3.3V, 1.5A |
| Voltage/Current - Output 3 | 1.2V ~ 3.3V, 1.5A |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | No |
| Grade | Automotive |
| Number of Outputs | 4 |
| Qualification | AEC-Q100 |
