NCV1117ST15T3G
IC REG LINEAR 1.5V 1A SOT223Manufacturer: onsemi
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The onsemi NCV1117ST15T3G is a positive fixed output linear voltage regulator with a 1.5V output voltage and a 1A maximum output current. This AEC-Q100 qualified device features over current and over temperature protection. The dropout voltage is specified at 1.2V at 800mA. Designed for surface mount applications, it is supplied in a SOT-223 package, also known as TO-261-4 or TO-261AA. It operates within an ambient temperature range of -40°C to 125°C and has a quiescent current of 10mA. Its power supply ripple rejection (PSRR) is 72dB at 120Hz. This component is suitable for automotive applications, including power management in various electronic control units.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-261-4, TO-261AA |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 10 mA |
| Voltage - Input (Max) | 20V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-223 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 1.5V |
| Control Features | - |
| Grade | Automotive |
| PSRR | 72dB (120Hz) |
| Voltage Dropout (Max) | 1.2V @ 800mA |
| Protection Features | Over Current, Over Temperature |
| Qualification | AEC-Q100 |
