NCP161BFCT330T2G
IC REG LINEAR 3.3V 450MA 4WLCSPManufacturer: onsemi
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The onsemi NCP161BFCT330T2G is a positive fixed output linear voltage regulator IC. This component delivers a stable 3.3V output with a maximum current capability of 450mA. Featuring a low quiescent current of 23 µA, it is suitable for power-sensitive applications. The NCP161BFCT330T2G incorporates over current, over temperature, and soft start protection features. Its high power supply rejection ratio (PSRR) of 91dB to 48dB across a frequency range of 100Hz to 100kHz ensures excellent noise immunity. The device operates from an input voltage up to 5.5V and has a dropout voltage of 0.26V at 450mA. It is supplied in a compact 4-WLCSP (0.64x0.64) surface mount package on tape and reel. This regulator finds application in portable electronics, automotive systems, and IoT devices.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-XFBGA, WLCSP |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 450mA |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 23 µA |
| Voltage - Input (Max) | 5.5V |
| Number of Regulators | 1 |
| Supplier Device Package | 4-WLCSP (0.64x0.64) |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.3V |
| Control Features | Enable |
| PSRR | 91dB ~ 48dB (100Hz ~ 100kHz) |
| Voltage Dropout (Max) | 0.26V @ 450mA |
| Protection Features | Over Current, Over Temperature, Soft Start |
