MC78L05ACP
IC REG LINEAR 5V 100MA TO92-3Manufacturer: onsemi
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The onsemi MC78L05ACP is a positive, fixed 5V linear voltage regulator. This TO-92-3 packaged component delivers a stable output current of up to 100mA. Designed for efficiency, it exhibits a quiescent current of 5.5 mA. The device offers robust protection against over-temperature and short circuits. With a maximum input voltage of 30V and a typical PSRR of 80dB at 120Hz, it is suitable for applications requiring clean power regulation. The MC78L05ACP finds utility in a range of industries including consumer electronics, industrial control, and automotive systems where reliable voltage stabilization is paramount. Its through-hole mounting type facilitates integration into various circuit designs.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 100mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 5.5 mA |
| Voltage - Input (Max) | 30V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-92-3 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | - |
| PSRR | 80dB (120Hz) |
| Voltage Dropout (Max) | - |
| Protection Features | Over Temperature, Short Circuit |
