L78MR05R-E
IC REG LINEAR 5V 500MA TO220-5HManufacturer: onsemi
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The onsemi L78MR05R-E is a positive fixed 5V linear voltage regulator with a 500mA output current capability. This component, housed in a TO-220-5H package with formed leads for through-hole mounting, offers robust protection against over current and over temperature conditions. Its design includes a reset function, contributing to system stability. The device is suitable for applications requiring stable voltage regulation with a maximum input of 20V. Key performance metrics include a Power Supply Rejection Ratio (PSRR) ranging from 80dB to 77dB at 120Hz. This regulator is commonly employed in industrial and automotive control systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-5 Formed Leads |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 500mA |
| Operating Temperature | -30°C ~ 80°C |
| Output Configuration | Positive |
| Voltage - Input (Max) | 20V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-220-5H |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | Reset |
| PSRR | 80dB ~ 77db (120Hz) |
| Voltage Dropout (Max) | - |
| Protection Features | Over Current, Over Temperature |
