FAN1581T25
IC REG LINEAR 2.5V 5A TO220-5Manufacturer: onsemi
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The onsemi FAN1581T25 is a positive fixed output linear voltage regulator with a 2.5V output voltage and a maximum output current of 5A. This TO-220-5 packaged component features an input voltage range up to 7V and a dropout voltage of 1.18V at 5A. Protection features include overcurrent and overtemperature shutdown. Its quiescent current is 6 mA, and it offers a Power Supply Rejection Ratio (PSRR) of 80dB at 120Hz. This device is commonly utilized in power supplies and consumer electronics applications requiring stable voltage regulation.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-5 |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 5A |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 6 mA |
| Voltage - Input (Max) | 7V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-220-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 2.5V |
| Control Features | - |
| PSRR | 80dB (120Hz) |
| Voltage Dropout (Max) | 1.18V @ 5A |
| Protection Features | Over Current, Over Temperature |
