CS8140YT7
IC REG LINEAR 5V 500MA TO220-7Manufacturer: onsemi
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The onsemi CS8140YT7 is a fixed 5V positive linear voltage regulator designed for efficient power management. This component, supplied in a TO-220-7 package, offers a robust 500mA output current. Key features include over-temperature and short-circuit protection, ensuring system reliability. The device operates across a wide temperature range of -40°C to 125°C, making it suitable for demanding industrial applications. With a typical dropout voltage of 1.5V at 500mA, it provides effective regulation. The CS8140YT7 also incorporates enable and reset control features, enhancing its utility in complex power supply designs. Its high power supply rejection ratio (PSRR) of 75dB at 120Hz is beneficial in noise-sensitive applications. This voltage regulator is commonly utilized in automotive, industrial control, and general-purpose power supply circuits.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-7 |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Voltage - Input (Max) | 26V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-220-7 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Control Features | Enable, Reset |
| PSRR | 75dB (120Hz) |
| Voltage Dropout (Max) | 1.5V @ 500mA |
| Protection Features | Over Temperature, Short Circuit |
