MV3750
LED RED CLEAR T-1 3/4 T/HManufacturer: onsemi
Categories: LED Indication - Discrete
Quality Control: Learn More
onsemi's MV3750 through-hole LED, with a T-1 3/4 package size, emits a clear red light when illuminated. This discrete component features a standard configuration with a forward voltage of 2.2V (typical) and operates at a test current of 20mA, delivering a luminous intensity of 150mcd. The domed top, clear red lens provides a focused 24° viewing angle. This component is suitable for various applications including industrial control and signaling systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 150mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Red |
| Current - Test | 20mA |
| Viewing Angle | 24° |
| Height (Max) | 8.89mm |
| Wavelength - Peak | 635nm |
| Wavelength - Dominant | - |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
