HLMP3950A
LED GREEN CLEAR T-1 3/4 T/HManufacturer: onsemi
Categories: LED Indication - Discrete
Quality Control: Learn More
The onsemi HLMP3950A is a through-hole mounted green LED, presented in a clear, domed T-1 3/4 package. This discrete indicator component features a forward voltage of 2.2V typical and operates at a test current of 20mA, delivering a luminous intensity of 150mcd. Its radial package and 24° viewing angle make it suitable for various industrial and consumer electronic applications demanding reliable visual feedback. The green emission is centered around a peak wavelength of 565nm. This component is provided in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Green |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 150mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Green |
| Current - Test | 20mA |
| Viewing Angle | 24° |
| Height (Max) | 12.19mm |
| Wavelength - Peak | 565nm |
| Wavelength - Dominant | - |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
