HLMP3301
LED RED DIFFUSED T-1 3/4 T/HManufacturer: onsemi
Categories: LED Indication - Discrete
Quality Control: Learn More
onsemi HLMP3301 is a red diffused T-1 3/4 through-hole LED designed for general indication. This discrete component features a standard configuration with a typical forward voltage of 2.2V at 10mA test current. The diffused red lens, with a diameter of 5mm (T-1 3/4), provides a wide 65° viewing angle and emits 7mcd luminous intensity. The component's package is radial, suitable for through-hole mounting. Its peak wavelength is 635nm. This LED finds application in industrial control, consumer electronics, and telecommunications equipment requiring reliable visual status indication. The HLMP3301 is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 7mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Red |
| Current - Test | 10mA |
| Viewing Angle | 65° |
| Height (Max) | 8.89mm |
| Wavelength - Peak | 635nm |
| Wavelength - Dominant | - |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
