QTLP610CIRTR
EMITTER IR 940NM 65MA SMDManufacturer: onsemi
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
onsemi QTLP610CIRTR is an infrared emitter designed for surface mount applications. This component features a 940nm wavelength and a forward voltage of 1.2V at a typical forward current of 65mA. The emitter provides a radiant intensity of 0.5mW/sr at 20mA, with a wide viewing angle of 160 degrees. Its side-view orientation and 2-SMD, No Lead package are suitable for compact designs. Operating within a temperature range of -40°C to 85°C, this device is commonly utilized in automotive, industrial, and consumer electronics sectors for applications such as proximity sensing, optical data transmission, and security systems. The QTLP610CIRTR is supplied in tape and reel packaging for automated assembly processes.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, No Lead |
| Wavelength | 940nm |
| Mounting Type | Surface Mount, Right Angle |
| Type | Infrared (IR) |
| Orientation | Side View |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Viewing Angle | 160° |
| Current - DC Forward (If) (Max) | 65mA |
| Radiant Intensity (Ie) Min @ If | 0.5mW/sr @ 20mA |
