NCL30388B1DR2G
IC LED DRVR CTRL DIM 4.7MA 7SOICManufacturer: onsemi
Categories: LED Drivers
Quality Control: Learn More
The onsemi NCL30388B1DR2G is a versatile DC-DC controller designed for LED driving applications. This component supports multiple topologies including Flyback, SEPIC, Buck, and Boost, offering flexibility for various power conversion needs. It features an integrated dimming function with an output current of 4.7mA and a nominal frequency of 150kHz. Operating within a supply voltage range of 8.2V to 30V, this device is suitable for demanding environments, with an operating temperature range of -40°C to 125°C. The NCL30388B1DR2G is presented in a 7-SOIC package, facilitating surface mount assembly. Its capabilities make it a key component in LED lighting systems. This part is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width), 7 Leads |
| Voltage - Output | 14V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Frequency | 150kHz |
| Type | DC DC Controller |
| Operating Temperature | -40°C ~ 125°C |
| Applications | LED Lighting |
| Current - Output / Channel | 4.7mA |
| Internal Switch(s) | No |
| Topology | Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) |
| Supplier Device Package | 7-SOIC |
| Dimming | Yes |
| Voltage - Supply (Min) | 8.2V |
| Voltage - Supply (Max) | 30V |
