LV52204MUTBG
IC LED DRV RGLTR PWM 700MA 6UDFNManufacturer: onsemi
Categories: LED Drivers
Quality Control: Learn More
The onsemi LV52204MUTBG is a single-output DC-DC boost regulator designed for LED driving applications. This component features PWM and single-wire dimming capabilities, allowing for precise control of LED brightness. With an internal switch rated for 700mA, it efficiently provides a regulated output for backlighting. The device operates at a switching frequency of 600kHz and is housed in a compact 6-UDFN (2x2) surface-mount package. Its input voltage range is 2.7V to 5.5V, and it is suitable for operation within an ambient temperature range of -30°C to 85°C. This component is commonly utilized in backlight circuits for various electronic devices.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-UDFN Exposed Pad |
| Voltage - Output | - |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Frequency | 600kHz |
| Type | DC DC Regulator |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 700mA (Switch) |
| Internal Switch(s) | Yes |
| Topology | Step-Up (Boost) |
| Supplier Device Package | 6-UDFN (2x2) |
| Dimming | PWM, Single-Wire |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
