FAN5333BSX
IC LED DRV RGLTR PWM SOT23-5Manufacturer: onsemi
Categories: LED Drivers
Quality Control: Learn More
The onsemi FAN5333BSX is a highly efficient DC-DC boost regulator designed for LED driving applications. This single-output device features a 1.5A internal switch, enabling it to deliver up to 30V output voltage from a 1.8V to 5.5V supply. The FAN5333BSX supports both analog and PWM dimming for precise brightness control, operating at a fixed frequency of 1.5MHz. Its compact SOT-23-5 package (SC-74A, SOT-753) is ideal for space-constrained designs, and it is supplied in tape and reel packaging for automated assembly. This component is commonly employed in backlight applications across various industries requiring efficient and controllable LED illumination.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Voltage - Output | 30V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Frequency | 1.5MHz |
| Type | DC DC Regulator |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 1.5A (Switch) |
| Internal Switch(s) | Yes |
| Topology | Step-Up (Boost) |
| Supplier Device Package | SOT-23-5 |
| Dimming | Analog, PWM |
| Voltage - Supply (Min) | 1.8V |
| Voltage - Supply (Max) | 5.5V |
