MAN8240
DISPLAY 7-SEG 0.8"" SGL RED 18DIPManufacturer: onsemi
Categories: LED Character and Numeric
Quality Control: Learn More
The onsemi MAN8240 is a single-digit, 0.80-inch height red 7-segment display module. Featuring a common cathode configuration, this component operates with a typical forward voltage of 1.8V and a test current of 20mA, yielding a millicandela rating of 3.3mcd. The display's physical dimensions are 0.985 inches in height, 0.735 inches in width, and 0.415 inches in depth. It is housed in an 18-DIP package with 14 leads, designed for standard through-hole mounting. The peak wavelength for the red emission is 650nm. This component is suitable for applications in industrial automation, consumer electronics, and instrumentation.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 18-DIP (0.600"", 15.24mm), 14 Leads |
| Color | Red |
| Display Type | 7-Segment |
| Size / Dimension | 0.985"" H x 0.735"" W x 0.415"" D (25.02mm x 18.67mm x 10.54mm) |
| Number of Characters | 1 |
| Millicandela Rating | 3.3mcd |
| Common Pin | Common Cathode |
| Digit/Alpha Size | 0.80"" (20.32mm) |
| Voltage - Forward (Vf) (Typ) | 1.8V |
| Current - Test | 20mA |
| Wavelength - Peak | 650nm |
| Power Dissipation (Max) | - |
Request a Quote
