LM2904DR2GH
IC OPAMP GP 2 CIRCUITManufacturer: onsemi
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
onsemi LM2904DR2GH is a dual, general-purpose operational amplifier. This component offers a wide operating voltage range from 3V to 26V and features a low supply current of 800µA. The input bias current is specified at 45 nA, with an input offset voltage of 2.9 mV. Each amplifier channel can deliver an output current of 40 mA. The device operates within a temperature range of -40°C to 85°C. This component is commonly utilized in industrial and automotive control systems, as well as consumer electronics. The LM2904DR2GH is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | - |
| Output Type | - |
| Mounting Type | - |
| Amplifier Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 800µA |
| Slew Rate | - |
| Current - Input Bias | 45 nA |
| Voltage - Input Offset | 2.9 mV |
| Supplier Device Package | - |
| Number of Circuits | 2 |
| Current - Output / Channel | 40 mA |
| Voltage - Supply Span (Min) | 3 V |
| Voltage - Supply Span (Max) | 26 V |
