AR0835HS3C12SUAA0-DR
IMAGE SENSORManufacturer: onsemi
Categories: Image Sensors, Camera
Quality Control: Learn More
The onsemi AR0835HS3C12SUAA0-DR is a high-performance CMOS image sensor featuring a 3264 x 2448 active pixel array. With a pixel size of 1.4µm x 1.4µm, this sensor is engineered for demanding imaging applications. It supports frame rates up to 46.0 fps, enabling detailed capture of dynamic scenes. The sensor operates within a voltage supply range of 1.14V to 1.3V and has an operating temperature range of -30°C to 70°C. Housed in a 48-CLCC (10x10) package, the AR0835HS3C12SUAA0-DR is suitable for industrial automation, automotive, and advanced surveillance systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-CLCC |
| Type | CMOS |
| Operating Temperature | -30°C ~ 70°C (TJ) |
| Voltage - Supply | 1.14V ~ 1.3V |
| Pixel Size | 1.4µm x 1.4µm |
| Active Pixel Array | 3264H x 2448V |
| Supplier Device Package | 48-CLCC (10x10) |
| Frames per Second | 46.0 |
