NVH640S75L4SPC
AUTOMOTIVE 750V, 640A SSDC POWERManufacturer: onsemi
Categories: IGBT Modules
Quality Control: Learn More
IGBT Module Three Phase Inverter 750 V 640 A 680 W Chassis Mount SSDC33
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 19 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Three Phase Inverter |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 1.64V @ 15V, 450A |
| NTC Thermistor | Yes |
| Supplier Device Package | SSDC33 |
| IGBT Type | - |
| Current - Collector (Ic) (Max) | 640 A |
| Voltage - Collector Emitter Breakdown (Max) | 750 V |
| Power - Max | 680 W |
| Current - Collector Cutoff (Max) | 500 µA |
| Input Capacitance (Cies) @ Vce | 47000 pF @ 30 V |
