NCP5358MNTXG
IC GATE DRVR HALF-BRIDGE 16QFNManufacturer: onsemi
Categories: Gate Drivers
Quality Control: Learn More
The onsemi NCP5358MNTXG is a half-bridge gate driver IC, supplied in a 16-QFN (4x4) package on tape and reel. This non-inverting driver is designed for N-channel MOSFET gates, featuring a high-side voltage capability of up to 30V, supported by a bootstrap function. The device operates within a supply voltage range of 10V to 13.2V and offers typical rise and fall times of 16ns and 11ns, respectively. With a 0°C to 150°C operating temperature range and a logic voltage threshold of 1V for VIL and 2V for VIH, the NCP5358MNTXG is well-suited for applications in power supplies, motor control, and automotive systems where efficient switching of power transistors is critical.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-VQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 150°C (TJ) |
| Voltage - Supply | 10V ~ 13.2V |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 30 V |
| Supplier Device Package | 16-QFN (4x4) |
| Rise / Fall Time (Typ) | 16ns, 11ns |
| Channel Type | Synchronous |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 4 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 1V, 2V |
| Current - Peak Output (Source, Sink) | - |
| Programmable | Not Verified |
