CAT24C01LE
EEPROM, 128X16, Serial, CMOS, PDIP8Manufacturer: onsemi
Categories: EEPROMs
Quality Control: Learn More
The onsemi CAT24C01LE is a 2Kbit (128 x 16 bit) serial CMOS EEPROM featuring I2C bus compatibility. Operating at clock frequencies up to 400 kHz, this component offers a data retention of 100 years and an endurance of 1 million write cycles. The CAT24C01LE supports a wide supply voltage range from 1.7V to 5.5V and operates within an industrial temperature range of -40°C to +85°C. Its memory organization is 128 words by 16 bits, with hardware write protection for data integrity. The device is housed in an 8-lead PDIP package with a 2.54mm terminal pitch, suitable for through-hole mounting. Applications include industrial control systems, automotive electronics, and consumer devices requiring non-volatile data storage. The I2C control byte format is 1010DDDR.
Additional Information
Series: CAT24C01RoHS Status: RoHS CompliantManufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Width | 7.6200 |
| Technology | CMOS |
| Length | 9.2700 |
| Clock_Frequency_Max | 0.40000 |
| Data_Retention_Time_Min | 100 |
| Endurance | 1000000.000000000000000 |
| I2C_Control_Byte | 1010DDDR |
| JESD_30_Code | R-PDIP-T8 |
| Memory_Density | 2048.0000000000000000 |
| Memory_IC_Type | EEPROM |
| Memory_Organization | 128X16 |
| Memory_Width | 16 |
| Number_of_Functions | 1 |
| Number_of_Terminals | 8 |
| Number_of_Words | 128.0000000000000000 |
| Number_of_Words_Code | 128 |
| Operating_Mode | Synchronous |
| Operating_Temperature_Max | 85.0 |
| Operating_Temperature_Min | -40.0 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | DIP |
| Package_Equivalence_Code | DIP8,.3 |
| Package_Shape | Rectangular |
| Package_Style | IN-LINE |
| Parallel_Serial | Serial |
| Seated_Height_Max | 5.3300 |
| Serial_Bus_Type | I2C |
| Standby_Current_Max | 0.000002000000000 |
| Supply_Current_Max | 2.000000000000000 |
| Supply_Voltage_Max | 5.50000 |
| Supply_Voltage_Min | 1.70000 |
| Supply_Voltage_Nom | 5 |
| Surface_Mount | No |
| Terminal_Form | THROUGH-HOLE |
| Terminal_Pitch | 2.540 |
| Terminal_Position | Dual |
| Write_Cycle_Time_Max_tWC | 5.0000000000000000 |
| Write_Protection | Hardware |
