MC14543BD
IC DRVR 7 SEGMENT 16SOICManufacturer: onsemi
Categories: Display Drivers
Quality Control: Learn More
The onsemi MC14543BD is a BCD-to-7 Segment Latch/Decoder/Driver for Liquid Crystal Displays (LCDs). This electronic component features a surface mountable 16-SOIC package, offering a standard footprint for board integration. Designed for demanding applications, it operates over a wide temperature range of -55°C to 125°C, ensuring reliability in various environments. The device accepts Binary Coded Decimal (BCD) inputs and converts them to the appropriate signals for driving a 7-segment LCD. With a low supply current of 10 µA and a voltage supply range from 3V to 18V, the MC14543BD is suitable for power-sensitive designs. Its functionality makes it a key component in instrumentation, industrial controls, and consumer electronics where clear display of numerical data is critical.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Display Type | LCD |
| Mounting Type | Surface Mount |
| Interface | BCD |
| Configuration | 7 Segment |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Supply | 3V ~ 18V |
| Digits or Characters | - |
| Supplier Device Package | 16-SOIC |
| Current - Supply | 10 µA |
