SBT150-04J
DIODE ARR SCHOTT 40V 15A TO220MLManufacturer: onsemi
Categories: Diode Arrays
Quality Control: Learn More
The onsemi SBT150-04J is a Schottky diode array featuring a common cathode configuration. This component offers a DC reverse voltage rating of 40V and an average rectified current capability of 15A per diode. With a low forward voltage drop of 550mV at 6A, it provides efficient rectification. The device exhibits a reverse leakage current of 200µA at 20V and is characterized by fast recovery times. Housed in a TO-220ML package, it is suitable for through-hole mounting. Operating across a temperature range of -55°C to 150°C, this diode array finds application in power supply circuits, switch-mode power supplies, and various industrial power control systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-3 Full Pack |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 15A |
| Supplier Device Package | TO-220ML |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 550 mV @ 6 A |
| Current - Reverse Leakage @ Vr | 200 µA @ 20 V |
