LC7865E
Digital Signal Processor, 0-Ext Bit, CMOS, PQFP64Manufacturer: onsemi
Categories: Digital Signal Processors
Quality Control: Learn More
The onsemi LC7865E is a CMOS Digital Signal Processor from the LC7865 series. This fixed-point processor features a PQFP64 package with a 0-bit address bus width and 0-bit external data bus width. It operates with a supply voltage range of 4.5V to 5.5V, nominal at 5.0V. The component utilizes a multiple internal bus architecture and is designed for surface mounting with a gull-wing terminal form and a 0.80mm terminal pitch. Applications for this device are found in various industrial and consumer electronics sectors.
Additional Information
Series: LC7865RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Format | Fixed Point |
| Width | 14.0000 |
| Technology | CMOS |
| Length | 14.0000 |
| Address_Bus_Width | 0 |
| Barrel_Shifter | No |
| Boundary_Scan | No |
| External_Data_Bus_Width | 0 |
| Integrated_Cache | No |
| Internal_Bus_Architecture | Multiple |
| JESD_30_Code | S-PQFP-G64 |
| Low_Power_Mode | No |
| Number_of_Terminals | 64 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | QFP |
| Package_Equivalence_Code | QFP64,.68SQ,32 |
| Package_Shape | Square |
| Package_Style | FlatPack |
| Seated_Height_Max | 2.7000 |
| Supply_Voltage_Max | 5.5000 |
| Supply_Voltage_Min | 4.5000 |
| Supply_Voltage_Nom | 5.0000 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 0.800 |
| Terminal_Position | QUAD |
| uPs_uCs_Peripheral_ICs_Type | DIGITAL SIGNAL PROCESSOR, OTHER |
