CAT5401WI-25-T1
IC DGTL POT 2.5KOHM 64TAP 24SOICManufacturer: onsemi
Categories: Digital Potentiometers
Quality Control: Learn More
The onsemi CAT5401WI-25-T1 is a digital potentiometer featuring a 2.5 kO resistance with a linear taper and 64 discrete taps. This component integrates four independent potentiometer circuits within a single 24-SOIC package. Communication and control are managed via an SPI interface, supporting selectable addresses for device identification. Designed for surface mount applications, it operates across a temperature range of -40°C to 85°C and accepts supply voltages from 2.5V to 6V. Key specifications include a typical wiper resistance of 200 O, a ±20% tolerance, and a temperature coefficient of 300ppm/°C. The non-volatile memory retains programmed resistance settings. This device is utilized in industrial automation, consumer electronics, and telecommunications systems. The CAT5401WI-25-T1 is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 2.5k |
| Tolerance | ±20% |
| Features | Selectable Address |
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SOIC (0.295"", 7.50mm Width) |
| Mounting Type | Surface Mount |
| Memory Type | Non-Volatile |
| Interface | SPI |
| Configuration | Potentiometer |
| Operating Temperature | -40°C ~ 85°C |
| Number of Taps | 64 |
| Voltage - Supply | 2.5V ~ 6V |
| Taper | Linear |
| Supplier Device Package | 24-SOIC |
| Resistance - Wiper (Ohms) (Typ) | 200 |
| Temperature Coefficient (Typ) | 300ppm/°C |
| Number of Circuits | 4 |
| Programmable | Not Verified |
