CAT5118TBI-10
CAT5118 - 32-TAP MINIPOT DIGITALManufacturer: onsemi
Categories: Digital Potentiometers
Quality Control: Learn More
The onsemi CAT5118TBI-10 is a 32-tap digital potentiometer featuring a 10k Ohm resistance. This single-circuit rheostat offers a linear taper and a ±20% tolerance, with a typical wiper resistance of 200 Ohms. It operates with a supply voltage range of 2.7V to 5.5V and a temperature coefficient of 200ppm/°C. The CAT5118 series component utilizes an Up/Down (U/D, CS) interface for control. Designed for surface mounting, it is packaged in a SOT-23-5 (SC-74A, SOT-753) configuration. This device is suitable for applications in consumer electronics and industrial control systems.
Additional Information
Series: CAT5118RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 10k |
| Tolerance | ±20% |
| Features | - |
| Packaging | Bulk |
| Package / Case | SC-74A, SOT-753 |
| Mounting Type | Surface Mount |
| Memory Type | - |
| Interface | Up/Down (U/D, CS) |
| Configuration | Rheostat |
| Operating Temperature | -40°C ~ 85°C |
| Number of Taps | 32 |
| Voltage - Supply | 2.7V ~ 5.5V |
| Taper | Linear |
| Supplier Device Package | SOT-23-5 |
| Resistance - Wiper (Ohms) (Typ) | 200 |
| Temperature Coefficient (Typ) | 200ppm/°C |
| Number of Circuits | 1 |
| Programmable | Not Verified |
