TN5D51A-R-HCC11-E
IC REG BUCK 12V 5A TO220F5I5H-HBManufacturer: onsemi
Categories: DC DC Switching Regulators
Quality Control: Learn More
The onsemi TN5D51A-R-HCC11-E is a 5A, 12V fixed output buck switching regulator IC. This component operates with an input voltage range of 20V to 48V and features a switching frequency of 150kHz. The device is packaged in a TO-220-5 Full Pack, Formed Leads (TO-220F5I5H-HB) configuration, suitable for through-hole mounting. It offers a single positive output and employs a non-synchronous buck topology. The operating temperature range is -10°C to 85°C. This regulator is utilized in power supply applications across various industrial sectors, including automotive and telecommunications.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-5 Full Pack, Formed Leads |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 5A |
| Operating Temperature | -10°C ~ 85°C |
| Output Configuration | Positive |
| Frequency - Switching | 150kHz |
| Voltage - Input (Max) | 48V |
| Topology | Buck |
| Supplier Device Package | TO-220F5I5H-HB |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 20V |
| Voltage - Output (Min/Fixed) | 12V |
Request a Quote
