NCV890101MWTXG
IC REG BUCK ADJ 1.2A 10DFNManufacturer: onsemi
Categories: DC DC Switching Regulators
Quality Control: Learn More
The onsemi NCV890101MWTXG is an adjustable output, 1.2A buck switching regulator designed for automotive applications. This device features a fixed switching frequency of 2MHz, contributing to a compact solution footprint. It operates over a wide input voltage range of 4.5V to 36V and provides an adjustable output voltage from 0.8V up to 34V. The NCV890101MWTXG is qualified to AEC-Q100 standards and operates within an ambient temperature range of -40°C to 150°C. Packaged in a 10-VFDFN exposed pad, this surface-mount component is supplied on tape and reel. Its positive output configuration and non-synchronous buck topology make it suitable for various automotive power management systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-VFDFN Exposed Pad |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 1.2A |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 2MHz |
| Voltage - Input (Max) | 36V |
| Topology | Buck |
| Supplier Device Package | 10-DFN (3x3) |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 34V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Grade | Automotive |
| Qualification | AEC-Q100 |
