KA34063A
IC REG BUCK BST ADJ 1.5A 8DIPManufacturer: onsemi
Categories: DC DC Switching Regulators
Quality Control: Learn More
The onsemi KA34063A is an adjustable positive or negative buck-boost switching regulator IC. This versatile component offers a single output capable of delivering up to 1.5A (switch) and operates with input voltages ranging from 3V to 40V. Featuring an adjustable output and a switching frequency range of 100Hz to 100kHz, the KA34063A is suitable for applications requiring efficient DC-DC conversion. Its through-hole mounting and 8-DIP (0.300", 7.62mm) package make it compatible with standard PCB assembly processes. This device is commonly employed in power supply designs across various industries including consumer electronics, industrial automation, and telecommunications. The KA34063A is provided in tube packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Output Type | Adjustable |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Function | Step-Up, Step-Down |
| Current - Output | 1.5A (Switch) |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Output Configuration | Positive or Negative |
| Frequency - Switching | 100Hz ~ 100kHz |
| Voltage - Input (Max) | 40V |
| Topology | Buck, Boost |
| Supplier Device Package | 8-DIP |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 3V |
| Voltage - Output (Min/Fixed) | - |
