UC3843AD2
CURRENT MODE PWM CONTROLLER 1AManufacturer: onsemi
Categories: DC DC Switching Controllers
Quality Control: Learn More
Boost, Buck, Flyback, Forward Regulator Positive, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
Additional Information
Series: -RoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up, Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | Up to 500kHz |
| Topology | Boost, Buck, Flyback, Forward |
| Voltage - Supply (Vcc/Vdd) | 7.6V ~ 30V |
| Supplier Device Package | 8-SOIC |
| Synchronous Rectifier | No |
| Control Features | Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 96% |
| Clock Sync | No |
| Number of Outputs | 1 |
