MC33067DWR2
IC REG CTRLR FLYBACK 16SOICManufacturer: onsemi
Categories: DC DC Switching Controllers
Quality Control: Learn More
The onsemi MC33067DWR2 is a versatile DC-DC controller designed for flyback topologies. This device facilitates step-up and step-down voltage conversion with a positive, isolation-capable output configuration. Featuring a high switching frequency of 2.05MHz, it enables efficient power conversion in a compact 16-SOIC package suitable for surface mounting. The controller integrates essential functions such as Enable and Soft Start, allowing for controlled power-up sequences. It is designed to operate within a supply voltage range of 8.6V to 20V and across an ambient temperature range of -40°C to 85°C. The MC33067DWR2 is commonly employed in power supply designs for consumer electronics, industrial automation, and telecommunications equipment, where efficient and isolated power conversion is critical.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | 2.05MHz |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 8.6V ~ 20V |
| Supplier Device Package | 16-SOIC |
| Synchronous Rectifier | No |
| Control Features | Enable, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | - |
| Clock Sync | No |
| Number of Outputs | 2 |
