NB3N511DG
IC CLOCK MULTIPLIER 8SOICManufacturer: onsemi
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
The onsemi NB3N511DG is a versatile clock multiplier designed for high-performance applications. This single-circuit device operates as a clock multiplier with a maximum frequency of 200MHz, accepting clock or crystal inputs. It features a 1:1 input-to-output ratio and generates CMOS/TTL outputs. The NB3N511DG is available in an 8-SOIC package (0.154"", 3.90mm Width) for surface mounting and operates across a temperature range of -40°C to 85°C. Its robust design and precise clock generation capabilities make it suitable for use in telecommunications, computing, and industrial control systems. The device operates from a voltage supply range of 3.135V to 5.25V.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Output | CMOS, TTL |
| Frequency - Max | 200MHz |
| Type | Clock Multiplier |
| Input | Clock, Crystal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.135V ~ 5.25V |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 8-SOIC |
| PLL | Yes |
| Divider/Multiplier | No/Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
