NB3N501DG
IC LL CLOCK MULTIPLIER 8SOICManufacturer: onsemi
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
The onsemi NB3N501DG is a low-loss clock multiplier with a maximum frequency of 160MHz. This single-circuit device, housed in an 8-SOIC package (0.154", 3.90mm width), accepts clock or crystal inputs and outputs CMOS or TTL compatible signals. It features a 1:1 input-to-output ratio and operates within a voltage supply range of 3V to 5.25V. The NB3N501DG is designed for robust performance across an operating temperature range of -40°C to 85°C. This component is commonly utilized in applications requiring precise clock generation and distribution, such as in networking infrastructure, consumer electronics, and industrial control systems. The device is supplied in a tube for efficient handling and integration into automated assembly processes.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Output | CMOS, TTL |
| Frequency - Max | 160MHz |
| Input | Clock, Crystal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 5.25V |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 8-SOIC |
| PLL | Yes |
| Divider/Multiplier | No/Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
