HLMPK155MP4A
LED CBI 3MM RED CLR RAManufacturer: onsemi
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
The onsemi HLMPK155MP4A is a single, red, tinted, round, domed top LED circuit board indicator. This 3mm, T-1 package component features a right-angle, through-hole mounting configuration. It operates at a forward voltage of 1.6V and a forward current of 1mA, with a peak wavelength of 660nm. The typical millicandela rating is 3mcd, and it offers a viewing angle of 45°. This component is commonly utilized in industrial automation, medical devices, and consumer electronics for status indication.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Current | 1mA |
| Color | Red |
| Voltage Rating | 1.6V |
| Mounting Type | Through Hole, Right Angle |
| Millicandela Rating | 3mcd |
| Configuration | Single |
| Viewing Angle | 45° |
| Lens Type | Tinted |
| Wavelength - Peak | 660nm |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
