HLMPK150MP4A
LED CBI 3MM RED CLEAR RAManufacturer: onsemi
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
onsemi HLMPK150MP4A is a single, red, diffused, tinted LED circuit board indicator. This component features a round, domed top lens with a 3mm (T-1) diameter and a right-angle, through-hole mounting style. Operating at a typical forward voltage of 1.6V and a forward current of 1mA, it achieves a luminous intensity of 2mcd with a peak wavelength of 660nm. The viewing angle is 60°. This component is commonly specified in industrial automation, consumer electronics, and medical equipment for status indication. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Current | 1mA |
| Color | Red |
| Voltage Rating | 1.6V |
| Mounting Type | Through Hole, Right Angle |
| Millicandela Rating | 2mcd |
| Configuration | Single |
| Viewing Angle | 60° |
| Lens Type | Diffused, Tinted |
| Wavelength - Peak | 660nm |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
