MC1413DG
TRANS 7NPN DARL 50V 0.5A 16SOManufacturer: onsemi
Categories: Bipolar Transistor Arrays
Quality Control: Learn More
The onsemi MC1413DG is a bipolar transistor array featuring seven NPN Darlington configurations. This component is designed for surface mounting within a 16-SOIC package. It offers a collector-emitter breakdown voltage of 50V and a maximum collector current (Ic) of 500mA. The minimum DC current gain (hFE) is rated at 1000 at 350mA and 2V. The saturation voltage (Vce Sat) is a maximum of 1.6V at 500µA base current and 350mA collector current. The operating temperature range extends up to 150°C (TJ). This device is commonly utilized in industrial automation, consumer electronics, and power management applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Transistor Type | 7 NPN Darlington |
| Operating Temperature | 150°C (TJ) |
| Power - Max | - |
| Current - Collector (Ic) (Max) | 500mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Vce Saturation (Max) @ Ib, Ic | 1.6V @ 500µA, 350mA |
| Current - Collector Cutoff (Max) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 1000 @ 350mA, 2V |
| Frequency - Transition | - |
| Supplier Device Package | 16-SOIC |
