CPH5518-TL-H
TRANS NPN/PNP 80V/50V 1A 5CPHManufacturer: onsemi
Categories: Bipolar Transistor Arrays
Quality Control: Learn More
The onsemi CPH5518-TL-H is a bipolar transistor array featuring one NPN and one PNP transistor configured in an emitter-coupled arrangement. This device offers a collector-emitter breakdown voltage of 80V for the NPN transistor and 50V for the PNP transistor. With a maximum collector current of 1A and a transition frequency of 420MHz, it is suitable for high-speed switching applications. The component boasts a DC current gain (hFE) of a minimum of 200 at 100mA and 2V, and a Vce saturation of 190mV at 10mA and 500mA. It dissipates a maximum power of 1.2W and operates at temperatures up to 150°C (TJ). The CPH5518-TL-H is supplied in a 5-CPH (SOT-23-5 Thin, TSOT-23-5) surface mount package, delivered on a tape and reel. This transistor array finds application in consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Mounting Type | Surface Mount |
| Transistor Type | 1 NPN, 1 PNP (Emitter Coupled) |
| Operating Temperature | 150°C (TJ) |
| Power - Max | 1.2W |
| Current - Collector (Ic) (Max) | 1A |
| Voltage - Collector Emitter Breakdown (Max) | 80V, 50V |
| Vce Saturation (Max) @ Ib, Ic | 190mV @ 10mA, 500mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 200 @ 100mA, 2V |
| Frequency - Transition | 420MHz |
| Supplier Device Package | 5-CPH |
