LC709204FXE-01TBG
IC FUEL GAUGE LI-ION 1C 12WLCSPManufacturer: onsemi
Categories: Battery Management
Quality Control: Learn More
The onsemi LC709204FXE-01TBG is a sophisticated battery monitor IC designed for single-cell Lithium Ion/Polymer battery management. This component, packaged in a compact 12-WLCSP (1.48x1.91) configuration, utilizes an I2C interface for seamless communication. Its robust design supports a wide operating temperature range of -40°C to 85°C, making it suitable for demanding applications. The LC709204FXE-01TBG is engineered for precision fuel gauging, crucial for applications in consumer electronics, portable medical devices, and industrial control systems where accurate battery status is paramount. The component is supplied on a tape and reel for efficient automated assembly.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 12-UFBGA, WLCSP |
| Number of Cells | 1 |
| Mounting Type | Surface Mount |
| Function | Battery Monitor |
| Interface | I2C |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Battery Chemistry | Lithium Ion/Polymer |
| Supplier Device Package | 12-WLCSP (1.48x1.91) |
| Fault Protection | - |
