NLAST4599DTT1G
IC SWITCH SPDT X 1 25OHM 6TSOPManufacturer: onsemi
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
The onsemi NLAST4599DTT1G is a single-circuit, double-pole, single-throw (SPDT) analog switch. This 2:1 multiplexer/demultiplexer features a low on-state resistance of 25 Ohms maximum, with channel-to-channel matching of 2 Ohms. The device operates over a supply voltage range of 2V to 5.5V and supports a -55°C to 125°C operating temperature. Key specifications include a 200MHz -3dB bandwidth, 10pF channel capacitance, and a charge injection of 3pC. Leakage current (IS(off)) is a maximum of 1nA. The NLAST4599DTT1G is supplied in a 6-TSOP surface mount package and is delivered on tape and reel. This component finds application in various electronic systems, including consumer electronics and industrial control.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C (TA) |
| On-State Resistance (Max) | 25Ohm |
| -3db Bandwidth | 200MHz |
| Supplier Device Package | 6-TSOP |
| Voltage - Supply, Single (V+) | 2V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | 3pC |
| Crosstalk | - |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 2Ohm |
| Switch Time (Ton, Toff) (Max) | 14ns, 8ns |
| Channel Capacitance (CS(off), CD(off)) | 10pF, 10pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Number of Circuits | 1 |
