NLAS1053USG
IC SWITCH SPDT X 1 16OHM US8Manufacturer: onsemi
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
The onsemi NLAS1053USG is a single-pole double-throw (SPDT) analog switch designed for 2:1 multiplexer applications. This component features a low on-resistance of 16 Ohms maximum and a -3dB bandwidth of 200 MHz, making it suitable for signal routing in various electronic systems. The device operates from a single supply voltage range of 2V to 5.5V and is specified for an extended operating temperature range of -55°C to 125°C. Key electrical characteristics include channel capacitance of 10pF (off-state) and a charge injection of 3pC. The NLAS1053USG is supplied in an 8-VFSOP (US8) surface-mount package, delivered on tape and reel. This switch finds application in consumer electronics and industrial automation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-VFSOP (0.091"", 2.30mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C (TA) |
| On-State Resistance (Max) | 16Ohm |
| -3db Bandwidth | 200MHz |
| Supplier Device Package | US8 |
| Voltage - Supply, Single (V+) | 2V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | 3pC |
| Crosstalk | - |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 2Ohm |
| Switch Time (Ton, Toff) (Max) | 8ns, 8ns |
| Channel Capacitance (CS(off), CD(off)) | 10pF, 10pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Number of Circuits | 1 |
