NCP1395APG
IC OFFLINE SW HALF-BRDG 16DIPManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
The onsemi NCP1395APG is an offline half-bridge controller designed for high-efficiency power conversion. This device supports switching frequencies ranging from 50kHz to 1MHz, enabling compact and optimized power supply designs. Featuring integrated soft-start and frequency control, the NCP1395APG facilitates robust operation. It incorporates essential fault protection mechanisms, including over-temperature and over-voltage protection, enhancing system reliability. The controller operates within a supply voltage range of 9.3V to 20V, with a startup voltage of 13.3V. Its 50% duty cycle capability and internal switch configuration are key design considerations. The NCP1395APG is housed in a 16-PDIP package suitable for through-hole mounting and is commonly utilized in AC-DC converters and offline switching applications across various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Duty Cycle | 50% |
| Frequency - Switching | 50kHz ~ 1MHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Output Isolation | Isolated |
| Topology | Half-Bridge |
| Voltage - Supply (Vcc/Vdd) | 9.3V ~ 20V |
| Supplier Device Package | 16-PDIP |
| Fault Protection | Over Temperature, Over Voltage |
| Voltage - Start Up | 13.3 V |
| Control Features | Frequency Control, Soft Start |
