NCP1200D100R2G
IC OFFLINE SWITCH FLYBACK 8SOICManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
onsemi's NCP1200D100R2G is an offline switching controller designed for flyback topologies. This 8-SOIC package facilitates surface mount integration into compact designs. Operating at a 100kHz switching frequency, it supports up to an 80% duty cycle. Integrated fault protection features include current limiting, overload, and short-circuit protection, enhancing system reliability. The NCP1200D100R2G is suitable for applications requiring isolated power conversion, commonly found in consumer electronics and industrial power supplies. Its maximum supply voltage is 16V, and it operates within an ambient temperature range of -25°C to 125°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -25°C ~ 125°C (TJ) |
| Duty Cycle | 80% |
| Frequency - Switching | 100kHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 16V (Max) |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting, Over Load, Short Circuit |
| Control Features | - |
