NCP1200AD60R2G
IC OFFLINE SWITCH FLYBACK 8SOICManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
The onsemi NCP1200AD60R2G is an AC-DC converter designed for flyback topologies. This offline switching controller operates at a fixed switching frequency of 60kHz. It features integrated fault protection, including current limiting, overload, and short-circuit protection, enhancing system robustness. The NCP1200AD60R2G supports a maximum supply voltage of 16V and a duty cycle of up to 83%. Housed in an 8-SOIC package for surface mounting, this component is suitable for applications demanding efficient power conversion in various industrial and consumer electronics sectors. The output isolation is inherent to the flyback topology.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Duty Cycle | 83% |
| Frequency - Switching | 60kHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 16V (Max) |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting, Over Load, Short Circuit |
| Control Features | - |
