NCP1200AD60R2
IC OFFLINE SWITCH FLYBACK 8SOICManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
The onsemi NCP1200AD60R2 is an offline switching controller designed for flyback topologies. This component operates at a fixed switching frequency of 60kHz and features an 8-SOIC package suitable for surface mounting. With a maximum supply voltage of 16V and an 83% duty cycle, it integrates comprehensive fault protection mechanisms, including current limiting, overload, and short-circuit protection. The device provides isolated output and is utilized in power supply applications across various industries such as consumer electronics, industrial automation, and telecommunications. The NCP1200AD60R2 is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Duty Cycle | 83% |
| Frequency - Switching | 60kHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 16V (Max) |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting, Over Load, Short Circuit |
| Control Features | - |
