NCP11187A065PG
IC OFFLINE SWITCH FLYBACK 7DIPManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Converter Offline Flyback Topology 65kHz 7-PDIP
Additional Information
Series: mWSaver™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm), 7 Leads |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Duty Cycle | 80% |
| Frequency - Switching | 65kHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | 800V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 7.8V ~ 16V |
| Supplier Device Package | 7-PDIP |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage, Short Circuit |
| Voltage - Start Up | 2.1 V |
| Control Features | EN |
| Power (Watts) | 65 W |
Request a Quote
