NCP1001PG
IC OFFLINE SWITCH MULT TOP 8DIPManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
onsemi NCP1001PG is an advanced offline switching controller designed for flyback and forward topologies. This component operates at a switching frequency of 100kHz and features an integrated 700V power switch. Key fault protection mechanisms include current limiting and over-temperature shutdown, ensuring robust operation. The device initiates operation with a low start-up voltage of 8.5V, requiring a supply voltage between 7.5V and 10V. With a maximum duty cycle of 72%, it is suitable for various power conversion applications, including consumer electronics and industrial power supplies. The NCP1001PG is housed in an 8-PDIP package for through-hole mounting, facilitating straightforward integration into existing designs. It provides isolated output and operates efficiently across a wide temperature range of -40°C to 125°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Duty Cycle | 72% |
| Frequency - Switching | 100kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Output Isolation | Isolated |
| Topology | Flyback, Forward |
| Voltage - Supply (Vcc/Vdd) | 7.5V ~ 10V |
| Supplier Device Package | 8-PDIP |
| Fault Protection | Current Limiting, Over Temperature |
| Voltage - Start Up | 8.5 V |
| Control Features | - |
