FSCQ1565RPVDTU
IC OFFLINE SW FLYBACK TO3PF-7LManufacturer: onsemi
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
The onsemi FSCQ series FSCQ1565RPVDTU is a high-performance offline quasi-resonant flyback controller designed for power supply applications. This device integrates a high-voltage MOSFET, PWM controller, and extensive fault protection features including over-current, over-load, over-temperature, and over-voltage protection. Operating with a switching frequency of 20kHz and a maximum duty cycle of 95%, it offers efficient power conversion up to 250W. The FSCQ1565RPVDTU features internal startup circuitry, requiring a Vcc of 9V to 20V and a startup voltage of 15V. Output isolation is provided by the flyback topology. The component is housed in a TO-3PF-7L (Forming) package with through-hole mounting and formed leads, suitable for applications requiring robust thermal performance. This device is commonly utilized in consumer electronics, industrial power supplies, and lighting applications where efficient and reliable offline power conversion is critical.
Additional Information
Series: FSCQRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-3PF-7, 5 Leads, Formed Leads |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Duty Cycle | 95% |
| Frequency - Switching | 20kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 9V ~ 20V |
| Supplier Device Package | TO-3PF-7L (Forming) |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage |
| Voltage - Start Up | 15 V |
| Control Features | Sync |
| Power (Watts) | 250 W |
