G6A-434P-ST-US-DC3
RELAY GENERAL PURPOSE 4PDT 1A 3VManufacturer: Omron Electronics Inc-EMC Div
Categories: Signal Relays, Up to 2 Amps
Quality Control: Learn More
General Purpose Relay 4PDT (4 Form C) Through Hole
Additional Information
Series: G6ARoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Mounting Type | Through Hole |
| Coil Voltage | 3VDC |
| Operating Temperature | -40°C ~ 70°C |
| Termination Style | PC Pin |
| Approval Agency | - |
| Relay Type | General Purpose |
| Coil Current | 120 mA |
| Coil Type | Non Latching |
| Seal Rating | - |
| Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Contact Form | 4PDT (4 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 250VAC, 220VDC - Max |
| Must Release Voltage | 0.3 VDC |
| Must Operate Voltage | 2.1 VDC |
| Operate Time | 7 ms |
| Release Time | 5 ms |
| Grade | - |
| Coil Insulation | - |
| Qualification | - |
| Load - Max Switching | 250VA, 220W |
