G5V-2-H1 DC9
RELAY GENERAL PURPOSE DPDT 1A 9VManufacturer: Omron Electronics Inc-EMC Div
Categories: Signal Relays, Up to 2 Amps
Quality Control: Learn More
General Purpose Relay DPDT (2 Form C) Through Hole
Additional Information
Series: G5V-2RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Mounting Type | Through Hole |
| Coil Voltage | 9VDC |
| Operating Temperature | -25°C ~ 70°C |
| Termination Style | PC Pin |
| Approval Agency | CSA, UR |
| Relay Type | General Purpose |
| Coil Current | 16.7 mA |
| Coil Type | Non Latching |
| Seal Rating | Sealed - Fully |
| Contact Material | Silver (Ag), Gold (Au) |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 125VAC, 125VDC - Max |
| Must Release Voltage | 0.45 VDC |
| Must Operate Voltage | 6.75 VDC |
| Operate Time | 7 ms |
| Release Time | 3 ms |
| Grade | - |
| Coil Insulation | - |
| Qualification | - |
| Load - Max Switching | - |
