G2E-134P-M-US DC5
RELAY GENERAL PURPOSE SPDT 1A 5VManufacturer: Omron Electronics Inc-EMC Div
Categories: Signal Relays, Up to 2 Amps
Quality Control: Learn More
General Purpose Relay SPDT (1 Form C) Through Hole
Additional Information
Series: G2ERoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Operating Temperature | -25°C ~ 60°C |
| Termination Style | PC Pin |
| Approval Agency | CSA, UL |
| Relay Type | General Purpose |
| Coil Current | 89 mA |
| Coil Type | Non Latching |
| Seal Rating | - |
| Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 125VAC, 60VDC - Max |
| Must Release Voltage | 0.5 VDC |
| Must Operate Voltage | 3.5 VDC |
| Operate Time | 5 ms |
| Release Time | 3 ms |
| Grade | - |
| Coil Insulation | - |
| Qualification | - |
| Load - Max Switching | 125VA, 60W |
